AVAYA CAMERAS HC020

Rs.39,000.00 Rs.25,999.00


AVAYA HUDDLE CAMERAS

HC020

▪ Affordable, enterprise capability for any size business

▪ Intuitive, easy to use

▪ Exceptional HD experience

▪ Easy to deploy



AVAYA CAMERAS

HC020



Now everyone can be in the room—without being in the room. Outfit small meeting rooms and huddle spaces with a full HD USB fixed camera that provides a 1080p30 video signal, a 105-degree horizontal field of view, and 8x digital zoom.

Avaya Huddle Cameras HC020 are the Avaya flexible solution for a wide range of scenarios, including personal and home use, but also huddle rooms for small groups. Huddle Cameras can be used with your laptop (PC or Mac), or with your CU360 or XT unit. When used with the laptop, the cameras can be controlled with their own remote (HC020 and HC050), or with a free software available on the support website (all models). When connected to CU360 and XT Room System user can enjoy full control through the codec Remote Control, Collaboration Control, Web Interface, and APIs

The huddle cameras deliver an exceptional experience for training, brainstorming, team and customer meetings with a personal connection. The ease of installation and use make them ideal for personal use, individual workgroups, small to mid-size businesses, or complementing an enterprise collaboration deployment.

Avaya Huddle Camera HC020 Suitable as laptop USB camera, or as optional camera for CU360 and XT Series. Fully integrated with Avaya Spaces®, Avaya Cloud Office®, Avaya One Cloud™ and Avaya Workplace, and interoperable with all third party cloud services. It is a full HD USB fixed camera, leveraging the quality of a UltraHD 4K sensor to provide a high quality 2160p30 video signal, with digital Pan Tilt Zoom (1080p resolution up to 2x zoom, 720p @3x zoom), and the option to send uncompressed signal on HDMI.

▪ Affordable, enterprise capability for any size business

▪ Intuitive, easy to use

▪ Exceptional HD experience

▪ Easy to deploy

The huddle cameras are great for enabling all of your small to medium meeting rooms and spaces, delivering utility, security, and an exceptional experience.

Technical Specifications:

Camera ModelHC020 1080p@30
Image Device4K@30/25 CMOS 1/2.7’’
Video Formats2160p30/25 – 1080p60/50/30/25
(up to 1080p30 on XT
720p30 on CU360)
Video SignalCompressed (H.264) on USB
Focal Lengthf=2.8mm
Min Object Distance (wide)500 mm
Min Illumination0.05 Lux @ (F1.8, AGC ON)
HFoV104° (up to 123°)
VFoV68° (up to 80°)
Optical Zoom (*)N/A
Digital Zoom (*)8x
Pan RangeePTZ
Tilt RangeePTZ
Serial ControlUVC via USB
Ceiling MountSupported
Camera MountTripod screw hole (1/4-20 UNC)
Weight0.34 Kg
Dimensions w/h/d194mm x 34mm x 42mm
Current Consumption (max)600mA
Avaya Clients SupportedAvaya Spaces®, Avaya Cloud Office®, Avaya Workplace, Avaya Equinox®, Avaya One Cloud™
3rd Party Clients SupportedMS® Teams, MS® SfB, Skype®, Zoom®, Bluejeans®, Starleaf®, Pexip®, Cisco Webex®, Google Hangouts®
Video ConfigurationsWhite balance (auto/manual); Focus Mode (auto/manual); Sharpness; Backlight; Exposure Compensation; Picture (auto/
manual) and WDR level
Voltage Range5V (USB power supply)
IR Repeater as TTL SignalNot available
Camera OutputUSB 3.0 – HDMI
MicrophoneIncluded
Presets10 when controlled from camera remote or UVC commands, 122 when controlled from XT or CU360
Far End Camera ControlThrough XT or CU360 codec (H.224, H.281) or third party App
×
